Attachment nozzle with expansion

Price on request or after logging in

plus shipping charges

  • Flaring to 210mm or 260mm
  • One side with Schmelzer flanging edge
  • Extremely high roundness
  • Less wear
  • Highest fitting accuracy

SKU: N/A Category:

TypeArticlenumberOld Articlenumberabcdet
DN 150x2, I = 122mm 2003463 4010014016036 161 mm 120 mm 150 mm 164 mm 20 mm 2 mm
DN 200x2, I = 122mm 1001070 4010014015988 210 mm 122 mm 199 mm 215 mm 20 mm 2 mm
DN 250x2, I = 122mm 1001071 4010014015989 260 mm 122 mm 249 mm 265 mm 20 mm 2 mm
DN 300x2, I = 122mm 1001072 4010014015990 310 mm 122 mm 299 mm 315 mm 20 mm 2 mm
DN 350x2, I = 122mm 1001082 4010014016037 360 mm 120 mm 349 mm 363 mm 20 mm 2 mm
DN 400x2, I = 122mm 1001083 4010014016038 410 mm 120 mm 399 mm 413 mm 20 mm 2 mm

You can find instruction manuals under the following link: Instruction manuals
