Telescope ventilation pipe DN 300 first pipe unperforated
Telescope ventilation pipe DN 300 first pipe unperforated - Image 2
Telescope ventilation pipe DN 300 first pipe unperforated - Image 3
Telescope ventilation pipe DN 300 first pipe unperforated - Image 4

Telescope ventilation pipe DN 300 first pipe unperforated

Price on request or after logging in

plus shipping charges; plus VAT

  • including extension cable
  • also suitable for rapeseed
  • easy handling and cleaning
  • air outlet area 22% of the total length
  • loadable up to 5m high
  • first tube unperforated
SKU: N/A Category:
TypeArticlenumberOld ArticlenumberPartsabcdkg
4 1002352 4009003016444 2 300 mm 2000 mm 3900 mm 300 mm 42
6 1002353 4009003016445 3 300 mm 2100 mm 5800 mm 300 mm 60
8 1002354 4009003016446 4 300 mm 2100 mm 7800 mm 300 mm 75
10 1002355 4009003016447 5 300 mm 2200 mm 9700 mm 300 mm 90
12 1002356 4009003016448 6 300 mm 2200 mm 12000 mm 300 mm 103
14 1002357 4009003016449 7 300 mm 2200 mm 14000 mm 300 mm 117
16 1002358 4009003016450 8 300 mm 2300 mm 15000 mm 300 mm 129
18 1002359 4009003016451 9 300 mm 2300 mm 17000 mm 300 mm 140
20 1002360 4009003016452 10 300 mm 2400 mm 19000 mm 300 mm 150
22 1004104 11 300 mm 2800 mm 22000 mm 316 mm 162
24 1004105 12 300 mm 2800 mm 23000 mm 332 mm 174
26 1004106 13 300 mm 2900 mm 25000 mm 349 mm 187
28 1004107 14 300 mm 2900 mm 27000 mm 365 mm 200
30 1004108 15 300 mm 3000 mm 29000 mm 381 mm 214

You can find instruction manuals under the following link: Instruction manuals
